Three Axis Automatic Robotic Palletizer For Sandwich Panels 20kg/m2

Name: Three Axis Automatic Robotic Palletizer For Sandwich Panels 20kgm2
Brand: LONGYU
Price: 20000.00 USD

Brand Name : LONGYU

Certification : ISO9001

MOQ : 1 Set

Price : 20000.00-30000.00

Payment Terms : T/T

Supply Ability : 1Set/month

Delivery Time : 45–60 Working Days

Packaging Details : Standard Export Wooden Case

Operating Temperature : 0°C to 45°C

Material : Aluminum alloy

Application : Assembly, welding, painting, material handling

Reach : 700 mm

Communication Interface : USB, Ethernet

Controlsystem : Programmable controller

Endeffectorcompatibility : Grippers, suction cups, welding tools

Productname : Robotic Arm

Contact Now

Three Axis Robotic Palletizer for Composite Board Stacking Automatic Sheet Feeding System

Specifications:

Item	Specification
Model	LY-08-1300
Machine Type	Three Axis Robotic Palletizer
Production Efficiency	4 pieces/min (3m board length)
Applicable Board Width	1–1.3m
Applicable Board Length	1–3m
Mechanical Arm Load	20kg/m² (Optional)
Maximum Stacking Height	1m (Optional)
Conveyor Chain Load	3 Tons (Optional)
Equipment Length	6m (Customizable)
Gas Source	0.6–0.8MPA
Power Supply	380V 50Hz Three Phase
Maximum Power	8KW

Description:

The LY-08-1300 Three‑Axis Robotic Palletizer is specifically engineered for automated sheet feeding and composite board stacking within continuous production lines. Common applications include sandwich panels, honeycomb boards, and industrial composite processing setups.

Utilizing a three‑axis motion control system, the robot delivers accurate positioning, reliable stacking accuracy, and smooth operational performance. Capable of handling up to four 3‑meter boards per minute, it substantially raises automation levels while lowering labor costs.

Its robotic arm is rated for a 20 kg/m² load, with customization options available to suit different board weights and dimensions. A 1‑meter maximum stacking height ensures secure and well‑organized palletizing.

When linked with conveyor systems, the unit forms a fully integrated automated material handling line. The conveyor chain can bear loads up to 3 tons, making it appropriate for heavy‑duty composite panels.

The machine has a standard length of 6 meters, which can be adjusted to meet specific factory layout needs. Operating on a three‑phase 380V/50Hz power supply, the equipment provides stable, energy‑efficient performance ideal for industrial production environments.

Three Axis Automatic Robotic Palletizer For Sandwich Panels 20kg/m2

Applications:

• Composite board stacking
• Honeycomb panel production lines
• Sandwich panel manufacturing
• Refrigerated truck panel handling
• Automated sheet feeding systems
